SERIES 6

Smart EV Charging for Commercial Applications

The smart EV charging station built for commercial applications

Smart EV Charging for Commercial Applications

The Series 6 smart EV charging station was designed with one goal in mind: To enable successful, robust EV charging programs in commercial settings such as multifamily, workplace, hotel, retail, government, and healthcare facilities.

Its compact form factor, ease of installation, and smart network capabilities make it the clear choice for any commercial application.

A Comprehensive Turnkey Solution

At New River Chargers, we provide a comprehensive turnkey solution for all of our customers to ensure that your electric vehicle charging station program is implemented and running smoothly.

We’ll guide you through the site selection for your new stations, help you select the appropriate station and mounting options, provide input on station installation, and even connect you with a local installer.

Interactive LED Lights

With eye-catching LED lights, EV drivers and station managers can quickly locate charging stations and understand their status:
Blue: Station is available for use
Pulsing Green: Station is currently charging
Steady Green: Station has completed charging
Red: Station has detected a ground fault
Easy to Locate

The bright LED lights make it quick and easy to find EV charging stations.

Status At-A-Glance

Know whether a station is available from across the parking lot.

All-Weather Construction

Built to withstand all types of weather – from heat to cold, rain to snow – the rugged aluminum enclosure prevents damage from nature and natural elements.
Built to Last

The Series 6 enclosure is built with rugged aluminum, making it more durable than other stations on the market.

Outdoor Rated

The Series 6 operates in temperatures as low as -22° F and as high as 122° F.

High Humidity Rating

The Series 6 can operate in up to 95% non-condensing humidity.

Compact, Modern Design

The Series 6 is compact in size and features a sleek design that complements your property.

Driver-Friendly Payment Methods

The Series 6 charging station offers EV drivers multiple convenient methods to pay for charging:
App & Website
New River Chargers Pass
Automated Phone System
Popular 3rd Party Apps

PlugShare, ChargeHub, EVgo, etc

Designed with Features Station Owners Love

4G LTE Wireless Technology

The Series 6 communicates with the cloud via built-in 4G LTE signal

Rugged Aluminum Enclosure

Prevents damage from nature and natural elements

Interactive LED Lights

Quickly locate stations and understand status with a bright LED light

Two-Line Backlit LCD Screen

Easily read pricing and pertinent station information

Built-In Electricity Metering

Manage electricity cost with an intuitive, smart network connection

Universal J1772™ Plug

Charge all electric and plug-in hybrid electric vehicles (Tesla vehicles require Tesla-provided adapter)

Convenient Access Panel

Panel makes installation and connectivity a breeze

Flexible Access Control & Pricing

Whether open to the public or completely private, station owners can easily manage driver groups

Flexible Access Control & Pricing

Whether open to the public or completely private, station owners can easily manage driver groups

Claim Incentives for Your EV Program

There may be incentives, grants, utility, or rebate programs in your region. Speak with a New River Chargers EV expert for more information.

Technical Specifications

  • Number of Ports: One
  • AC Current, Maximum (Per Port): 30A
  • AC Power Output, Maximum (Per Port): Level II: 7.2 kW (240VAC@30A) or 6.24 kW (208VAC@30A)
  • AC Power Input (Per Port): Level II: 30A; Line 1, Line 2, and GND (no neutral)
  • Input Connector: Hardwired
  • Vehicle to Charger Connection (Per Port): SAE J1772 EV Connector
  • Energy Metering Accuracy: +/- 1%
  • Standby Power (Per Port): 4.11 W Typical
  • Service Panel Breaker (Per Port): Dual-pole common trip 40A breaker, dedicated circuit
  • ENERGY STAR: Compliant
  • California Type Evaluation Program (CTEP) Compliance: California Code of Regulations (CCR) National Institute Standards and Technology (NIST) Handbook 44 Section 3.40
  • Safety, Ground Fault Circuit Interrupt: 20mA CCID with auto retry (every 15 seconds)
  • Automatic Plug-Out Detection: Power terminated per SAE J1772 spec: SMS or email notification
  • Surge Protection: 6kV @3,000A
  • Safety Compliance: UL 2231-1, 2231-2, UL 2594, and NEC Article 625
  • EMI Compliance: FCC Part 15 Class A
  • Data Communication: Cellular 4G LTE
  • Communication Protocol: OCPP Compliant
  • Firmware Management: Over-the-Air (OTA) update enabled
  • LED Array: High visibility, multi-color visual status indication
  • Display: LCD Screen – 2 line, 16 characters per line
  • RFID Reader: ISO14443 Type A & B, MiFare, Felicia; NFC, ISO15693
  • Enclosure: Aluminum, NEMA 3R outdoor rated
  • Operating Humidity: Up to 95% non-condensing
  • Operating Temperature: -22° F to 122° F ambient (-30° C – +50° C)
  • Dimensions: 25” H x 6” W x 6” D
  • Approximate Weights:
    • Device: 15.5 lbs.
    • Pedestal Mount: 9 lbs.
    • Wall Mount Bracket: 9 lbs.
  • Installation: Indoor/Outdoor
  • Mounting Option: Integrated wall and pedestal mount
  • Cable Length: 18 ft. standard, 25 ft. optional
  • Cable Organizer: Optional
SERIES 7
The Smart Charging Station Business Owners Can Rely On
The Series 7 smart EV charging station enables property managers to build the charging infrastructure needed to support electric vehicles at your property.
With its compact form factor, ease of installation, and commercial-grade aluminum body, the Series 7 charging station is the perfect charger for your electrified fleet or business.
Learn More
SERIES 8
The Most Flexible and Convenient EV Charging Station Available
The Series 8 smart charging station was designed for commercial applications where drivers are likely to pay with a credit card or a digital wallet. This means no membership is required for drivers to charge their electric vehicle making it perfect for all commercial settings including shopping malls, hospitals, municipal parking, and any retail location. The Series 8 is available in both 48A and 80A.
Its compact form factor, ease of installation, and smart network capabilities make it the clear choice for any commercial application.
Learn More
